- The HE M62P8 and Smoke M64P2 bullets are completed with the firing cartridge and 6 increments of charge M74 (0+6) and the Illumination M87Pl projectile is completed with the firing cartridge and 5 waterproof increments of sM74 (0+5).
- High safety during transport, handling and parachuting.
- Reliable function of the shell is achieved in the temperature range of -30°C to 50°C.
| Caliber | Length by Use | Weight depending on use | Insurance | maximum range | Minimum Range | Maximum Pressure in Barrel | |
|---|---|---|---|---|---|---|---|
| HEM62P8 | 120mm | 606mm | 12.6kg | UTU M93Pl SQ/Detective | 6500m | 255m | 961 bars |
| lighting M87/P1 | 120mm | 606mm | 12.6kg | TPM67 pyrotechnics | 6000m | 250m | 620 bars |
Full set:
HEM62P8
- 1 full shell per carton
- 2 cartons per wooden case
- Wooden packaging box:
- dimensions: 710x350x180 mm
- gross weight: 38kg
- volume: 0.045 m2
Illuminator M87Pl
- 1 full shell per carton,
- 2 cartons per wooden case
- Wooden packaging box:
- * dimensions: 780x350xl 80 mm
- * gross weight: 35 kg
- * volume: 0.049 m2
